037126 Gauge, Tachometer; 0-4000 RPM, Alternator Pulse, 12-24 VDC | Heavy Equipment Accessories
List Price :
$68.61
Price :
$61.75 (You Save $6.86)
Brand :
CPP
SKU :
TL-037126
Weight :
2.50 LBS
Warranty :
Same as Komatsu
Availability :
Ships in 24 Hours
037126 Gauge, Tachometer; 0-4000 RPM, Alternator Pulse, 12-24 VDC
Gauge, Tachometer; 0-4000 RPM, Alternator Pulse, 12-24 VDC | 037126
Gauge, Tachometer; 0-4000 RPM, Alternator Pulse, 12-24 VDC
- Range: 0-4000 RPM
- Volt: 12-24 VDC
- Sender: Alternator/Ignition Coil
- Size: 3-3/8"
- Operating Temperature Range: -40 DegreesF to + 158 DegreesF (-40 DegreesC to + 70 DegreesC)
- Humidity: Remains within initial accuracy specification in 5% relative humidity at 100 DegreesF (37.8C) for 48 hours
- Overvoltage: Withstands a maximum of 18 VDC for 12 VDC nominal, 30 VDC for 24 VDC nominal
- Salt Spray: Conforms to ASTM 117 after 48 hours of salt spray exposure
- Shock Withstand: Remains within initial accuracy specification up to 50 G's, half sine 9 milliseconds duralions, 25 shocks of equal magnitude on each of three axes
- Vibration Withstand: Remains within initial accuracy specification at .060" double amplitude vibration from 10-55-10 Hz for one minute periods over two hours in each of three axes (six hours total)
PARTS CROSS-REFERENCE
Item # Manufacturer Part # Manufacturer 037126 103684 DATCON 037126 TD5157 Faria (12V Only)
Gauge, Tachometer; 0-4000 RPM, Alternator Pulse, 12-24 VDC
- Range: 0-4000 RPM
- Volt: 12-24 VDC
- Sender: Alternator/Ignition Coil
- Size: 3-3/8"
- Operating Temperature Range: -40 DegreesF to + 158 DegreesF (-40 DegreesC to + 70 DegreesC)
- Humidity: Remains within initial accuracy specification in 5% relative humidity at 100 DegreesF (37.8C) for 48 hours
- Overvoltage: Withstands a maximum of 18 VDC for 12 VDC nominal, 30 VDC for 24 VDC nominal
- Salt Spray: Conforms to ASTM 117 after 48 hours of salt spray exposure
- Shock Withstand: Remains within initial accuracy specification up to 50 G's, half sine 9 milliseconds duralions, 25 shocks of equal magnitude on each of three axes
- Vibration Withstand: Remains within initial accuracy specification at .060" double amplitude vibration from 10-55-10 Hz for one minute periods over two hours in each of three axes (six hours total)
PARTS CROSS-REFERENCE
| Item # | Manufacturer Part # | Manufacturer |
|---|---|---|
| 037126 | 103684 | DATCON |
| 037126 | TD5157 | Faria (12V Only) |
