153040 40 Amp High Amp Breaker | Heavy Equipment Accessories

40 Amp Manual Reset Automotive High Amp Circuit Breaker

• Manual Reset Circuit Breaker
• Automotive Type III
• High Current - Waterproof
• Voltage: 42 VDC Maximum (32VDC inchin¦‚Å“ CURUS approved)
• Amperage: 40A
• Interrupting Rating: 3000A @ 30VDC
• IP Rating: IP67
• Material: Frame: Thermoset Plastic, UL rated 94-V0 Stud Insulators: EPDM plastic
• Mounting Torque: 40in-lb Max.
• Stud Torque: 50in-lb Max.
• Overall Dimensions: 2 x 3
• ABYCE-11 compliant
• Designed to Meet SAE J1625, SAE J1171, UL1500(Ignition Protected)

Time Characteristics:

• 100% of Rated Current - No Trip
• 135% of Rated Current - 30m Max. hold time
• 200% of Rated Current - 12s Min. hold time, 45s Max. hold time
• 300% of Rated Current - 3.5s Min. hold time, 15s Max. hold time
