1703161 Hid 24v Spot Globe (Rep: 1701031) | Jw Speaker

List Price :
Price :
$862.52 (You Save $95.83)
Brand :
Weight :
15.00 LBS
Warranty :
Same as Komatsu
Availability :
Ships in 24 Hours

1703161 Hid 24v Spot Globe (Rep: 1701031) | Jw Speaker

Hid 24v Spot Globe (Rep: 1701031) | 1703161

JW Speaker Model 9720 4x6 HID Light, 24V Spot

High Intensity Discharge lighting provides unmatched lighting performance, greatly extended life and resistance to shock and vibration. With an extended service life, HID lighting offers 8-10 times the life of today's conventional halogen lamps.

Applications: Agriculture, construction, forestry, mining, ground support


  • Voltage: 24 VDC
  • Current Draw: Peak (1 second) 10 Amps; Nominal 1.59 Amps @ 24v
  • Beam pattern: Spot
  • Lens: Glass
  • Connector: Integrated 2-pin Deutsch connector (DT04-2P)
  • Mating connector:
  • Dimensions: 6.15" W x 8" T (top to bottom of bracket) x 6.41" D
  • Brilliant, blue-white light
  • Stainless steel mounting hardware for flat surpaces
  • 5 times the light of Halogen
  • 10 times the life of Halogen
  • Completely sealed from water, dust and corrosion
  • Highly resistant to shock, vibration and the elements
  • Standards: IP68 rated

Warranty: All Speaker HID products are warranted against defects in material and workmanship for one year from the original date of purchase. Products found to be defective during the warranty period will be repaired or replaced (at JW Speakers option).

Warranty void if plug removed - please use mating plug part#
