24-360EP 60a At 12v And 40a At 24v | 24360EP | Heavy Equipment Accessories

List Price :
$8.00
Price :
$7.20 (You Save $0.8)
Brand :
CPP
SKU :
TL-24-360EP
Weight :
1.50 LBS
Warranty :
Same as Komatsu
Availability :
Ships in 24 Hours

24-360EP 60a At 12v And 40a At 24v | 24360EP

60a At 12v And 40a At 24v | 24-360EP

Momentary Push Switches - 2 Position: Off- On, Normally Off (Push to On)

Momentary push-button switches function by having an operator push the actuating device (plunger) and contacts which transfer the circuits to a second set of contacts. When the actuating force is removed, the actuating device and the contacts return to the original position.

  • OperationL 50,000 Cycles
  • Mounting Stem: 5/8-32 Thred
  • Accommodates panels up to 1/4" thick
  • Contact Rating: @ 14 VDC: Make 70 Amps, Break 20 Amps Inductive Load; @ 28 VDC: Make 35 Amps, Break 10 Amps Inductive Load
  • Zinc Die-Cast Housing
  • Silver-plated contacts
  • Housing rolled over insulator to seal out Dust and Moisture
  • #25-358 Cape and Face Nut to seal out Weather and Dust
  • Hex Back Nut
  • Overall Length: 1-13/16"
  • Housing Diameter: 15/16"

More Information
Availability Of stock Ships in 24 Hours
Google Product Category Business & Industrial > Construction
